P. 55
(C) linear response range (50mmHg increments for the choices). (A) Target bladder inflation pressure of 10mmHg. (B) Target bladder inflation pressure of 12mmHg. (C) Target bladder inflation pressure of 15mmHg. (D) Target bladder inflation pressure of 18mmHg. (E) Target bladder inflation pressure of
21mmHg.
(E)
(B)
FIGURE 4 Constrained bladder versus chamber pressures.
(D) On each panel, the y- and the x-axes have the same scale and show gauge pressure (absolute pressure – atmospheric pressure). Individual data points are shown in the indicated color for each inflated bladder pressure (legend on each graph). A line of perfect agreement with y = 1 ✕ x + 0 is shown on each graph. Grid lines on each graph indicate the chamber pressure range
(A)
Pressure Measuring System | 51
