IMPACT 754 VENTILATOR: IN-FLIGHT EMERGENCIES
Alternative for Missing Internal Compressor Air Filter

A ventilator inspiratory bacteria filter can be attached to the air inlet. (Missing air filters allow
dust, debris, and/or moisture to be pulled into the ventilator compressor. This results in increased
workload of the ventilator, leading to diminished battery life and eventual compressor failure.)
COMMON REPLACEMENT PARTS
Zoll/NSN Part Numbers
Zoll Part #: 820-0097-15 Oxygen reservoir kit for low-pressure supply
• MEDSILS: OXYGEN ADAPTER BLEED-IN RESERVOIR FOR VENTILATORS
• NSN: 6515-01-518-5060
Zoll Part #: 704-0754-01 Battery Pack
• MEDSILS: BATTERY POWER SUPPLY USED ON VENTILATOR
• NSN: 6130-01-468-8361
Zoll Part #: 490-0005-00 Valve, Leaf
• MEDSILS: VALVE REGULATING SYSTEM PRESSURE
• NSN 6530-01-464-0267

198 • PROCEDURES
